ENERPAC CYLINDER PRECISION DOUBLE ACTING 8T X 28MM BRD91
Category:
BRD SERIES
- Designed for long life, the best choice for production applications
- Unique mounting configurations simplify fixturing
- Baked enamel finish for increased corrosion resistance
- Double-acting operation develops force in both directions, providing maximum versatility
- Plunger wiper reduces contamination, extending cylinder life
Specifications
| Maximum Operating Pressure (bar) | 700 |
| Minimum Operating Pressure (bar) | 35 |
| Capacity Class (tonnage) | 9 |
| Maximum Cylinder Capacity Advance (kN) | 80 |
| Maximum Cylinder Capacity Retract (kN) | 44 |
| Stroke (mm) | 28 |
| Collapsed Height A (mm) | 223 |
| Extended Height B (mm) | 251 |
| Return Type | Double-Acting, Hydraulic Return |
| Cylinder Effective Area Advance (cm2) | 11,4 |
| Cylinder Effective Area Retract (cm2) | 6,3 |
| Oil Capacity Advance (cm3) | 32 |
| Oil Capacity Retract (cm3) | 18 |
| Cylinder Capacity Advance At 350 (bar) | 40,0 |
| Cylinder Capacity Retract At 350 (bar) | 21,8 |
| Surface Treatment | Paint |
| Weight (kg) | 3,0 |
